Introduction
These days the demand of smart phone is being increased and we have
different types of client e.g. Touch Phone, tables, Note etc. The
demands of the applications for these smart clients are constantly
increasing and we have several operating systems for these smart clients
e.g. Android, IOS and Windows etc. This article will provide a
guideline to .net developer or beginners to develop Android Application.
Development Environment
This Article is not focusing on how to install/Configure
development environment, you can find different development environment
on internet. In this article, I will use “
eclipse mobile juno” development environment.
Create New Project
For creating new project click on the File -> New -> Project.
It opens the new wizard window where you can select application
template and set the name of the project and package name.
On the click on Next Button, it moves to the next step. Here
provide the “Application Name”, “Project Name” and “Package Name”.
“Package Name” is a same as “Name Space” in .Net and it must be unique.
The project name is only used by Eclipse and it must be unique in the
workspace.
You also need to select “Minimum Required SDK” from dropdown. It
is the lowest version of Android that your application will support.
Then select “Target SDK” which is the Highest API that the application
is known to work with. Then select the installed SDK for “Compile With”
option to compile your code for selected targeted SDK.
In the next steps of the wizard, you need to select icons, some
other information and on the last step provide the name of your activity
and it's Navigation Type.
I will provide the detail of activity and layout later, for now
you can say it is window’s form as desktop application or as a Web page
in web application. Provide the name of Activity and Layout. Leave
Navigation type “None” for now. Press finish button. Eclipse will
automatically generate start up activity for you.
Within the Eclipse, you can see your project in the “Package
Explorer” pane of the left-hand side of the screen. The “HelloWorld”
application contains several auto generated folders and file. Let’s
discuss it one by one.
-
/Src: It contains the all java source
files those are associated to the project. For example the
MainActivity.java file generated by Eclipse is stored in this directory
under the package name “com.MyFirst.helloworld” you specified in the
wizard. You can add more packages for your application e.g.
com.MyFirst.Fragments, CommonClasses etc.
-
/gen: It contains the java source files
and other code files generated by Eclipse. We will use R.java file code
later in our project. This file is generated to link your resource
files for use in your java files in /src folder.
-
Andriod Directories (/Android 4.2 and /Android Dependencies):
The Android 4.2 directory is generated against your selected Android
SDK and Dependencies folder the support file is generated for the
backward compatibility with previous versions of Android SDK.
-
/assests: By default this is empty
folder, but you can put your raw assets in it and these files include in
your projects as-is. For Example it is good location for textures and
game data.
-
/bin: It is the output directory for build. You can find the final .apk file and other compiled resources in this folder.
-
/libs: It contains the private libraries (jar) those you might want to use in your application.
-
/res: It contains all the resources
files those are associated to your application. All the graphical
element, string and layout of application exists one of the sub folder
of the res. We will add some resource later in this project. The auto
generated layout file “activity_main.xml” by Eclipse exists in layout
sub folder.
-
Project.properties: This file is
generated by android project wizard and it is used for Eclipse settings.
It is very rare to change this file directly. Instead Right click on
the project in Eclipse and click on properties and make any change which
is required for your application.
Run Your Application in Emulator
First you need to configure emulator for testing your
application. To configure your emulator click on window -> Android
Virtual Device Manager
It will open pop up where you can create new Virtual device,
Edit exist and start any virtual device. After create your new virtual
device close this window. Now right click on the application in “Package
Explorer” pane on the left-hand side of the screen and click on Run As
-> Android Application. It will compile your application and execute
it in the emulator.
After a few minutes the emulator will be started and you will be able to see your HelloWorld application in it.
On the screen you can see Status Bar, Action Bar and Navigation
Bar. You have nothing to do with the Status Bar and Navigation Bar, it
is being managed by System. The Action bar contains the logo and title
of your application and you can also open menu by click Menu button
(three vertical dots) on it. Layout Area where we place all UI controls.
Design Layout
As it is mentioned earlier Eclipse generates by default one
layout. In emulator the application is showing only “Hello World!” text
in the middle of the screen. Open the layout from
/res/layout/activity_main.xml and you can see the layout in designer in
the middle area Eclipse. You can change view from graphic or xml as per
your wish. Eclipse provides you both option in the bottom of the layout
“Graphical Layout” or “activity_main.xml”.
In the designer you can see all available controls for UI design
in different tabs e.g. Text Fields, Layouts etc. I will create a UI
given below in image for understanding the basic component of Android
application. Let’s start playing with the layout.
This layout is designed using Linear Layout.
LinearLayout is a view group that aligns children in single direction, Horizontal or Vertical. The attribute
android:orientation is used to set the direction. E.g.
android:orientation="vertical". Eclipse provides a Property Pan on the right-hand side of the screen to set the properties from designer.
TextView control is a readonly text. You can only view it and cannot edit it.
EditText control is use for getting input from the user.
Button is a standard button control and on the click event we perform action accordingly.
Collapse | Copy Code
<LinearLayout
xmlns:android="http://schemas.android.com/apk/res/android"
android:layout_width="match_parent"
android:layout_height="match_parent"
android:orientation="vertical">
<TextView
android:layout_width="fill_parent"
android:layout_height="30dp"
android:background="@drawable/header_bg_royal"
android:paddingLeft="8dp"
android:paddingTop="6dp"
android:text="@string/intent_title"
android:textColor="@color/white_color"
android:textStyle="bold" />
<LinearLayout
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:layout_marginTop="10dp"
android:layout_marginBottom="10dp">
<Button
android:id="@+id/btn_phone_call"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:text="@string/phone_call_title" />
<Button
android:id="@+id/btn_map_application"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:text="@string/map_title" />
</LinearLayout>
<TextView
android:layout_width="fill_parent"
android:layout_height="30dp"
android:background="@drawable/header_bg_royal"
android:paddingLeft="8dp"
android:paddingTop="6dp"
android:text="@string/activity_title"
android:textColor="@color/white_color"
android:textStyle="bold" />
<LinearLayout
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:layout_marginTop="10dp"
android:layout_marginBottom="10dp">
<Button
android:id="@+id/btn_open_activity"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:text="@string/open_activity_title" />
</LinearLayout>
.
.
.
</LinearLayout>
One thing you must notice in this UI, I haven’t registered any
event for the buttons here in layout. We can do here using
onClick attribute,
but it is not a good way to do here. Now it is time to understand the
some properties/attributes of different UI elements.
Properties
layout_width & layout_height: These properties are used for setting the width and height of the element. The possible values are “
fill_parent”, “
match_parent”, “
wrap_content” and any number (e.g. 100dp). The
fill_parent and
match_parent are same.
fill_parent is renamed to
match_parent in API level 8 and higher, which means that the view want to as big as parent (minus padding).
wrap_content means set the width or height according to the content or child.
android:background="@drawable/header_bg_royal":
This property is similar to the other programming languages to set
background of the element. The interesting point here is to set the
background from the resources of the android application. The
header_bg_royal is the image which I pasted in the
res/drawable-hdpi. You can see complete path in the image below.
In layout xml file we can access resources using
@ sign at the start of resource name.
@drawable
means get the resource from the drawable folder. You can see more than
one drawable folders e.g. drawable-hdpi, drawable-ldpi etc. The reason
for multiple folders is we have large verity of client machine some is
using tables, Note, mobiles etc. The screen size and resolution varies
client to client. You can create your icons, image for different
resolution and put it into the appropriate folder. Android OS will
automatically pick best suitable image for displaying.
@drawable/header_bg_royal means get
header_bg_royal image/resource from
drawable.
android:text="@string/intent_title": I hope you have understood what purpose of
@ sign is and what does string means after it and what
intent_title
is. Before explaining it again, let me explain why I need to put all my
strings in the resource files. If I hard code the text of any control
in xml file, the Eclipse gives warning to move it into the resource
file. You can see warning in the image given below, when I set the
button text property is “Button”, Eclipse is giving warning message to
move it into the
string resource file.
The question is why it should be string resource. Although you
can hardcode it, but it is not a good programming practice. Suppose you
have 10 occurrence of text in different activities or layout. For
changing that text you need to go into each activity/layout and change
there. If you put that text in the string resources then the change
require only one place. You can also create your application
multilingual using these resource files.
@string/intent_title means get the value of
intent_title from the
string resource.
android:textColor="@color/white_color": For
setting the fore color of the text, get color value from resource file.
In next section you will get to know how can we add value in resource
file.
android:id="@+id/btn_phone_call": If you want to access any control in code, assign it an id. The
+ sign with
@ means if the resource exist then use it otherwise create it.
@+id/btn_phone_call mean use the
btn_phone_call in id resource and if it does exists then create it.
Resource File
Eclipse provides you a provision to add resources using
designer. You can also use xml view to add resources. You can add
different type of resources e.g. string, color, array etc. I will not go
in the detail of resources in this article. You can read more about it
in different tutorials.
Activity
It is a most important concept of Android development. An
activity represents the screen in an application. You can use it in
different ways as floating window or embedded inside of another activity
etc. The class must be inherited from
Activity class for your activity.
extends keyword is used for inheritance in java.
Collapse | Copy Code
public class MainActivity extends Activity {
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_main);
}
@Override
public boolean onCreateOptionsMenu(Menu menu) {
getMenuInflater().inflate(R.menu.activity_main, menu);
return true;
}
}
onCreate method is used to initialize your activity. We usually call
setContentView() method to define the layout for the activity and also get UI controls using
findViewByid() that are required to interact programmatically.
super.onCreate() means call the
onCreate method of base class.
Super is used to access the base class in java. The layout that is associated with this activity is in
activity_main.xml. You can get the id of that resource using
R.layout.activity_main.
R is the auto generated class that maintains the resources and we use it to access to resources in code.
setContentView(R.layout.activity_main) sets the layout for activity.
onCreateOptionsMenu() method is used to handle the menu for that activity. I will explain it later.
Access Control/View in Activity
After setting the content view of the activity, you can get control using
findViewById(viewId) method. It takes the view/control id as a parameter and returns the view that is found.
View is
the base class for widgets, which are used to create interactive UI
components (buttons, text fields, etc.). We need to cast the
view into the original widgets.
Collapse | Copy Code
Button btnPhoneCall = (Button)findViewById(R.id.btn_phone_call);
EditText txtName = (EditText)findViewById(R.id.txt_name);
In above sample code
findViewById(R.id.btn_phone_call) finds the button having id passed as parameter and finds the
by id. Now after finding we can use these Views/Controls in our code.
Now we need to register a click event of the button and on click we will
open phone call view of android.
Collapse | Copy Code
btnPhoneCall.setOnClickListener(new OnClickListener() {
@Override
public void onClick(View v) {
onPhoneCallClick();
}
});
There are three ways to implement listeners in java and they
have their own advantages and disadvantages. These three ways are
- Inline implementation
- Using the implements keyword
- By using variables
You can study about these different ways on the internet. In the
above example I register listener for button using Inline
implementation. Call
setOnClickListener() method of button and pass
OnClickListener as an parameter. In
OnClickListener handler override the
onClick event. When user will click on button, it will call
onClick event. You can write your code inside
onClick.
Intent
Intent is the asynchronous message which allows
android components to request functionality from the other component of
the Android System. It represents an app’s ‘Intent to do something’. We
can use intents for different tasks e.g. making call, open map, open
activity etc. But most often they are used to start another activity.
How to Start another Activity
Till here, you have learnt about activity, layout resources and intent. Create another activity name “
LifeCycleActivity” and create its layout “
activity_life_cycle.xml”
in layout folder. It is better to use Eclipse to add activity in your
application that automatically generates layout for that activity and
automatically put necessary information of activity in “
AndroidManifest.xml” file. Otherwise you need to do it manually. Right click on your application in “
Package Explorer” pane in left-hand side and click on
New > Other. It will open a popup window where you need to select “
Android Activity” and after completing the wizard, it will create a Activity and default layout for you.
Create object of Intent class and pass it to the
startActivity() method.
Intent class has different type of constructor, for starting activity pass context and activity class to the object.
Activity class
is the subclass of context, so pass this as a first parameter and the
pass the class as to which the system should deliver the intent. Then
pass this intent to the
startActivity() method and your second activity will be started.
Collapse | Copy Code
Intent intent = new Intent(this, LifeCycleActivity.class);
startActivity(intent);
There are some other methods for starting activity. You can study about them too.
- startActivityForResult(intent, requestCode)
- startActivityFromChild(child, intent, requestCode)
- startActivityFromFragment(fragment, intent, requestCode)
Open Phone Dialer
Launching the Phone dialer is also quite easy in Android you can
send message to Android OS to run specific application using intent
Collapse | Copy Code
Uri uri = Uri.parse("tel:03361122334");
Intent intent = new Intent(Intent.ACTION_VIEW,uri);
startActivity(intent);
When you create asynchronous message (intents) from the
Uri, tells the system to open activity that can handle the
Uri scheme. In above example the
Uri start from tel: loads an activity from the phone dialer application with the number loaded.
Pass data to another Activity
You can easily pass data with your asynchronous message (intent)
as we passed to the phone dialer activity. But we passed to phone
dialer activity using
Uri. You can also put string, integer or other values in intent and you can also put your custom class object. Use
intent.putExtra() method to put extra information in your intent. This method has many overloaded method, use appropriate method for your data.
Collapse | Copy Code
Student std = getStudent();
Intent intent = new Intent(this, DetailActivity.class);
intent.putExtra("student", (Serializable)std);
startActivity(intent);
The activity “
DetailActivity” that is receiving the intent exposes the method for retrieving the extra information. The
getIntent() method returns the intent and then you can get extra information using
getExtras()
method. This method returns the bundle and from the bundle you can get
your desired information using get methods as per your information type.
In this example I am calling “
(Student)bundle.getSerializable("student");” because my information was serialize able object and then I am casting it back to my concrete class object.
Collapse | Copy Code
Bundle bundle = this.getIntent().getExtras();
Student std = (Student)bundle.getSerializable("student");
String name = std.getName();
Lifecycle of the Activity
For proper understanding of the activities, it is necessary to
understand the life cycle of the activity. Activities are managed in the
system as an activity stack. When new activity started it is placed on
the top of the stack and becomes the running activity. The previous
activities always remain below it in the stack and will not come to the
front until the new activity exists. Following is the list of method
which calls on each state of the activity.
Collapse | Copy Code
@Override
protected void onCreate(Bundle savedInstanceState) {
}
@Override
protected void onStart() {
}
@Override
protected void onRestart() {
}
@Override
protected void onResume() {
}
@Override
protected void onPause() {
}
@Override
protected void onStop() {
}
@Override
protected void onDestroy() {
}
onCreate() method called when activity is first created.
onStart() called when activity is visible to user and
onResume() called when application starts interaction with the user. At this point your activity comes at the top of activity stack.
onPause() method called when system is about to
start resuming of previous activity. It is typically used to save the
unsaved data to persist it, stop animation or other work that can
consume CPU.
onStop() method called when the activity is no
longer visible to the user, because another activity has been resumed
and is covering this one.
onRestart() called after your activity has been stopped. It called prior to being started again.
onDestroy() called before your activity is destroyed.
Create Menu
For creating menu, open the
res/menu/activity_main.xml
file and add your menu items in it. Set id and title for each menu item
and then you can handle this menu item by id in activity class.
Collapse |
Copy Code
<menu xmlns:android="http://schemas.android.com/apk/res/android" >
<item
android:id="@+id/menu_settings"
android:showAsAction="never"
android:title="@string/menu_settings"/>
<item
android:id="@+id/menu_other"
android:showAsAction="never"
android:title="@string/menu_other"/>
<item
android:id="@+id/menu_exit"
android:showAsAction="never"
android:title="@string/menu_exit"/>
</menu>
For handling on click method of the menu item override the
onOptionsItemSelected(MenuItem item)
method in your activity. This method fires whenever user click/select
any menu item. For handling different actions for each element get the
id of the selected menu item using
getItemId() method and perform action for each menu item.
Collapse | Copy Code
@Override
public boolean onOptionsItemSelected(MenuItem item) {
boolean handled = false;
int id = item.getItemId();
switch(id)
{
case R.id.menu_settings:
{
Toast.makeText(this, "Clicked on setting menu item.", Toast.LENGTH_SHORT).show();
handled = true;
break;
}
case R.id.menu_other:
{
onOpenActivity();
handled = true;
break;
}
case R.id.menu_exit:
{
finish();
handled = true;
break;
}
default:
{
handled = super.onOptionsItemSelected(item);
}
}
return handled;
}
Each activity can has its own menu. You can put different menu items for
each activity and handle it differently. Some activity cannot have any
menu. For this don’t override
onCreateOptionsMenu method in your activity. In this method we inflate menu items to
menuInflater.
